Our plastic curb stone molds are specialized precision tools for manufacturing uniform, durable cement prefabricated curb stones. Designed for heavy-duty commercial and industrial construction applications, these reusable molds provide a reliable, cost-effective alternative to cumbersome steel molds.
Wangzu operates a complete digital quality control system covering every stage from raw material inspection to finished product testing. Every batch of molds undergoes rigorous performance verification to ensure consistent quality and long service life, making them ideal for large-scale infrastructure projects and high-volume precast production facilities.
Primary material is food-grade virgin engineering polypropylene (PP), with optional ABS plastic available for specialized high-impact requirements. This material offers exceptional properties tailored for construction use:
Non-toxic, odorless and 100% recyclable, compliant with global environmental standards
High tensile strength, excellent stiffness and superior hardness
Heat resistance up to 100℃, suitable for use in most climate conditions
Outstanding anti-aging properties, maintaining performance over repeated use
High electrical insulation and moisture resistance
All molds are manufactured using state-of-the-art injection molding technology with strict process control:
Quantitative feeding of raw materials to ensure consistent material composition
High-temperature melting and plasticizing at 200-280℃ for uniform material flow
Precision pressure injection into precision-machined mold cavities
Controlled cooling to prevent warping and ensure dimensional accuracy
Automatic mold lifting and finishing inspection
This fully monitored process guarantees a cavity size error of ≤ 0.5mm, ensuring every curb stone produced meets exact engineering specifications.
Our molds feature a convex letter-shaped single parting surface design, optimized for easy demolding and structural integrity. This design supports production of various complex curb stone profiles, including arcs, chamfers, curved edges and custom decorative patterns to meet diverse project requirements.
Every feature of our molds is designed to solve the most common pain points of precast concrete producers:
Ultra-fast demolding: Smooth, non-porous cavity surface minimizes concrete adhesion. Demolding time is only 1/4 of steel molds, allowing for multiple production cycles per day
Lightweight and labor-efficient: 65-80% lighter than equivalent steel molds, easily moved by a single worker. Eliminates the need for cranes or heavy lifting equipment, reducing labor costs by up to 50%
Long service life: Can be reused for -100 concrete pouring cycles with proper maintenance (regular application of demolding agent)
Low total cost of ownership: 30-50% lower initial cost than steel molds, with no rust prevention, painting or frequent repair requirements
Feature | Wangzu Plastic Curb Mold | Traditional Steel Mold |
|---|---|---|
Initial Investment | 30-50% Lower | Higher |
Weight per Unit | 2-5kg (1 person movable) | 10-25kg (crane needed) |
Average Demolding Time | 15-20 minutes | 60-80 minutes |
Daily Production Output | 4× Higher | Standard |
Customization Cost | Low | Very High |
Maintenance Requirements | Minimal (demolding agent only) | Rust prevention, welding, frequent repairs |
Parameter | Specification |
|---|---|
Product Name | Plastic Roadside Stone Box Mold |
Brand | Wangzu |
Standard Size | 50×30×10.5cm |
Core Material | 100% Virgin Engineering PP |
Cavity Size Tolerance | ≤ 0.5mm |
Reusable Cycles | -100 concrete pouring cycles |
Customization Options | Sizes, shapes, logos, colors |
Quality Control | Full-process digital QC with traceable production records |
Stock Availability | 10000+ units (standard sizes) |
Custom Lead Time | 7-15 days |
Additional standard sizes are available upon request, and we can develop fully custom molds based on your engineering drawings.
Municipal Road Construction: Standard 100×500×120mm molds for general urban roads, used to define road boundaries, guide drainage and create pedestrian safety zones
Highway Infrastructure: Reinforced heavy-duty molds for national highways and expressways, providing collision protection and durable road edge definition
High-speed Railway Projects: Precision 750×300×120mm molds for high-standard railway curb construction, meeting strict dimensional and durability requirements
Residential & Commercial Developments: Custom molds for parking lots, sidewalks and landscape projects, offering design flexibility for aesthetic requirements
Trusted by hundreds of construction companies and government agencies, our molds have consistently delivered superior performance and cost savings on projects of all scales.
Raw Material Inspection: All incoming PP particles are tested for purity, melt flow rate and mechanical properties before entering production
In-process Monitoring: Hourly inspections of cavity dimensions, surface smoothness and structural integrity to catch any deviations early
Finished Product Testing: 100% of molds undergo demolding simulation and pressure testing to verify performance
Pre-shipment Verification: Final inspection of packaging and quantity before dispatch, with full documentation provided
Full Traceability: Each batch is assigned a unique identification number, with complete production records available for customer review at any time
We offer complete ODM and OEM services to meet your unique project requirements. Our experienced engineering team can develop custom molds based on your drawings, samples or design specifications, providing detailed design proposals within 24 hours. We support customization of sizes, shapes, surface patterns and company logos.
Sample Policy: Samples are available for quality evaluation (shipping cost borne by the customer)
Order Processing: Standard orders ship within 2-7 days of payment confirmation
Packaging: Export-standard carton packaging, or custom packaging as per your requirements
Shipping Arrangements: We handle all logistics for FOB and CIF orders, and provide full assistance with shipping arrangements for EXW orders
Yes, we specialize in custom mold manufacturing. Simply send us your drawings, samples or detailed specifications, and our engineering team will provide a detailed quote and design proposal within 24 hours.
With proper use and regular application of demolding agent, our molds can be reused for -100 concrete pouring cycles. Actual lifespan may vary slightly depending on concrete mix, curing conditions and maintenance practices.
Our plastic molds offer 30-50% lower initial cost than steel molds, with significantly lower maintenance and labor costs. Most importantly, they enable 4× faster demolding, allowing you to produce more curb stones per day with the same equipment and workforce.
Yes, we provide comprehensive technical support including detailed operation manuals, maintenance guides and video tutorials. Our technical team is available to answer any questions and provide troubleshooting assistance throughout the life of your molds.
